GD-2

Air hydraulic twin ram pit jack

  • Features

    ✓ 2 individually controlled rams offer safe and balanced lifting

    ✓ Rapid and precise air hydraulic unit with high speed ram travel

    ✓ Simple modern design with control panel at ergonomical working height

    ✓ Transversely sliding rams

    ✓ Can be made to fit all pits due to its adjustable frame

    ✓ Frame height is adjusted and set to the customers individual specifications

    ✓ Comprehensive option range: cross beam, support bridge etc.

    ✓ Supplied with 2 x100 mm extensions


    Note: The support arms are not a part of the product and must be ordered separately.

  • Winning Offer Flyer

    Download Pit Jacks

Specification GD200-2
Capacity 20 t
Stroke 420 mm
Min. height 545 mm
Max. height 945 mm
Width¹ 590-1410 mm
Depth 650 mm
Lifting points² 200-1160 mm
Air supply 8-12 bar
Air consumption 350 l/min
Weight (÷ support arms) 220 KG
